軸承型號 | 外形尺寸 Boundary Dimensions | 額定載荷 Load Rating | 重量 Weight | ||||
| d | D | B | rmin | 動負荷 Cr | 靜負荷 Cor | ||
| 16004 | 20 | 42 | 8 | 0.3 | 7.90 | 4.45 | 0.050 |
| 16005 | 25 | 47 | 8 | 0.3 | 8.42 | 5.15 | 0.060 |
| 16006 | 30 | 55 | 9 | 0.3 | 11.2 | 6.25 | 0.085 |
| 16007 | 35 | 62 | 9 | 0.3 | 11.5 | 8.80 | 0.100 |
| 16008 | 40 | 68 | 9 | 0.3 | 12.5 | 10.2 | 0.130 |
| 16009 | 45 | 75 | 10 | 0.6 | 12.8 | 10.2 | 0.170 |
| 16010 | 50 | 80 | 10 | 0.6 | 16.2 | 13.2 | 0.180 |
| 16011 | 55 | 90 | 11 | 0.6 | 19.4 | 16.2 | 0.260 |
| 16012 | 60 | 95 | 11 | 0.6 | 19.9 | 17.5 | 0.280 |
| 16013 | 65 | 100 | 11 | 0.6 | 20.5 | 18.6 | 0.300 |
| 16014 | 70 | 110 | 13 | 0.6 | 27.9 | 25.0 | 0.430 |
| 16015 | 75 | 115 | 13 | 0.6 | 28.7 | 26.8 | 0.460 |
| 16016 | 80 | 125 | 14 | 0.6 | 33.1 | 31.4 | 0.600 |
| 16017 | 85 | 130 | 14 | 0.6 | 34.0 | 33.3 | 0.630 |
| 16018 | 90 | 140 | 16 | 1 | 41.5 | 39.3 | 0.850 |
| 16019 | 95 | 145 | 16 | 1 | 42.7 | 41.9 | 0.890 |
| 16020 | 100 | 150 | 16 | 1 | 43.8 | 44.3 | 0.910 |
| 16021 | 105 | 160 | 18 | 1 | 52 | 50.5 | 1.24 |
| 16022 | 110 | 170 | 19 | 1 | 57.5 | 56.5 | 1.51 |
| 16024 | 120 | 180 | 19 | 1 | 56.5 | 57.5 | 1.6 |
| 16026 | 130 | 200 | 22 | 1.1 | 75.5 | 77.5 | 2.4 |
| 16028 | 140 | 210 | 22 | 1.1 | 77.5 | 82.5 | 2.84 |
| 16030 | 150 | 225 | 24 | 1.1 | 84 | 91 | 3.62 |
| 16032 | 160 | 240 | 25 | 1.5 | 99 | 108 | 4.20 |
| 16034 | 170 | 260 | 28 | 1.5 | 114 | 126 | 5.71 |
